BTech OPC UA Server – Siemens
The OPC UA Server for Siemens offers a standardized data exchange with Siemens S7 and Siemens compatible controllers. By using the Siemens S7 protocol, this server is particularly powerful with regard to data transfer between the controller and the internal node system. The server can establish communication channels to any number of controllers, and is not limited with regard to the number of nodes. A significant advantage is the import feature for importing variables from the Tia Portal.
Perks
- Import model from Tia Portal project
- Secure connection through encryption and signing
- Existing communication drivers can be included for highjperformance
- Record historical data, store in SQL databases or CSV files
| Technical Specifications | request | |
|---|---|---|
| Operating Systems: | Windows XP, Windows 7, Windows 8, Windows Server 2003, Windows Server 2008, Windows 8.1 Linux Ubuntu, Linux Debian, Embedded Linux Ubuntu, Embedded Linux Debian | |
| Siemens Controls: | S7 200, S7 300, S7 1200, S7 1500, Vipa - Siemens kompatibel | |
| Address Types: | DB, DI, DO, AI, AO | |
| Data Types: | Bool, Byte, Date_and_Time, String, Word, Int, Real, Date, DWord, DInt, Felder der angegebenen Datentypen |
Complementary Software Packages - OPC UA Products
| Automation Studio One | - Configuration tool for all BTech-Studio products |
| Automation Studio OPC UA Server Weidmüller | - Symbolic data access to Weidmüller u-remote |
| Automation Studio OPC UA Server Allen Bradley | - High-performance data access to AB and Rockwell controllers |
| BTech OPC UA Server SDK | - Development package for the implementation of OPC UA Server applications |
| BTech OPC UA Client SDK | - Development package for the implementation of OPC UA client applications |
| Automation Studio OPC UA Siemens Server | - Free tool to test OPC UA connections |
